6-Port LC Duplex OM3 Multimode Fiber Wall Box, Compact IP65 Termination Enclosure with 6 LC Couplers, Gray
FYBOPTWU
- SKU
- FOD-FWB-6P-LCD-OM3
- Weight
- 1.00 LBS
- Shipping
- Free Shipping
Key Features
- Fitted with 6 LC duplex OM3 multimode couplers
- Compact multimode termination point for small offices, IDF closets and equipment rooms
- OM3 laser-optimized fiber supports 10G Ethernet over in-building runs
- Small-form LC connectors match most modern switches and transceivers
- IP65 rated to keep out dust and moisture, indoors or out
- Sturdy PC+ABS housing that resists aging
- Screw-mount design installs quickly on walls, backboards or cabinet sides
- Space-saving 8.77 x 5.31 x 1.57 in footprint
Description
When you only need a handful of multimode connections, this compact 6-port wall box keeps things simple. It comes installed with six LC duplex OM3 couplers, giving you a clean, dedicated termination point for short-reach links in small offices, retail spaces, classrooms, IDF closets and equipment rooms.
OM3 multimode fiber is a common choice for 10 Gigabit Ethernet inside buildings, and LC connectors are the go-to interface for today’s network switches and SFP+ transceivers. Land your horizontal or riser cable, splice it in, and patch directly to your gear without buying separate adapters.
The PC+ABS enclosure is IP65 rated to protect connections from dust and moisture, and it screws easily onto drywall, plywood backboards or the side of a cabinet. Even with its small size, there’s room inside to splice and store slack while keeping a safe bend radius. The gray finish blends in with standard network hardware.
Specification
| Specification | Value |
|---|---|
| Product Type | Wall mount fiber termination box with couplers |
| Port Count | 6 |
| Included Couplers | 6 x LC duplex |
| Fiber Mode | OM3 50/125 multimode |
| Functions | Cable entry, fusion splicing, slack storage, termination, distribution |
| Material | PC+ABS |
| Protection Rating | IP65 |
| Usage | Indoor and outdoor |
| Color | Gray |
| Installation | Wall mount, screw-in |
| Dimensions | 8.77 x 5.31 x 1.57 in (223 x 135 x 40 mm) |
| Weight | 3.2 oz (91 g) |
| Application | Small office LAN, IDF closets, equipment rooms, classrooms, retail |
